Main input voltage
230 V
Type of product or component
Uninterruptible Power Supply (UPS)
Different input voltage
220 V
240 V
Base output voltage
230 V
Other output voltage
220 V
240 V
Rated power [W]
6000 V
Rated power [VA]
6000 VA
Type of output connector
Integral three-wire (phase + neutral + ground) 1
Battery Type
Lead-acid battery
Battery voltage
192 V
Pre-installed batteries
0
Number of empty battery compartments
0
Battery recharge time
4 hours
Battery life
is 3...5 years
Charger power (W)
235 V rated
Colour
Black (RAL 7010)
Height
68.5 cm
Width
19 cm
Depth
37.4 cm
Net weight
54 kg
Installation location
The front part
Preferred installation location
No preferences
Mounting method
It is not mounted in a rack
USB-compatible
Yes
Mounting position
Vertical
Input voltage limits
110...300 V, 60% load
176...300 V full load
Number of connectors for inputs
1 built-in three-wire wire (phase + neutral + ground)
Network frequency
automatic detection 40...70 Hz
Maximum configured power [VA]
6000 VA
Maximum configured power [W]
6000 V
Output frequency
50/60 Hz +/- 3 Hz, synchronized with the power grid
Harmonic distortion
1%
Type of UPS
Double conversion
Type of wave
Sinusoidal signal
Performance factor
94% (full load)
Additional information
Possible configuration for operation with a rated output voltage of 220: 230 or 240 V.
Bypass type
Internal bypass (with automatic or manual activation)
The amplitude coefficient
is 3:1
