Main Input voltage
230 B
Other Input voltage
220 B
240 B
Main Output voltage
230 V
Other Output voltage
220 V
240 V
Rated power [W]
10000 W
Rated power
10000 VA
Type of output connection
All-in-one three-wire (1P + N + E) 1
Number of Units
4U
Battery Type
Lead-acid battery
Battery voltage
192 V
Pre-installed batteries
0
Free battery compartments
0
Typical recharge time
5 h
battery life
3…5 year(s)
Charger power (W)
235 W rated
Colour
Black (RAL 7010)
Height
17,3 cm
Width
43,8 cm
Depth
71,0 cm
Net weight
68 kg
Installation location
Front
Type of fastener
Lower
Installation execution
Rack
USB-compatible
Yes
Mounting position
Horizontal
Input voltage limits
110...300 In 60 % load
176...300 V full load
Number of input connections
1 All-in-one three-wire (1P + N + E)
Network frequency
40-70 Hz auto detection
Maximum specified power (VA)
10000 VA
Maximum set power (W)
10000 W
Output frequency
50/60 Hz +/- 3 Hz synchronized with the power grid
Harmonic distortion
1 %
Type of UPS
Topology double transformation
Type of voltage form
Sinusoidal signal
EFFICIENCY
94 % (full load)
bypass type
Internal bypass (automatic and manual)
Cross factor
3:1
