Standards
IEEE 802.11ax at 2.4GHz IEEE 802.11ax at 5 GHz
Backward compatible with 802.11b/g/n/ac standards.
Processor
Qualcomm® ARM Cortex A53s Quad-core processor with 2.0 GHz
Antenna
4 x 2.4GHz: 3 dBi 4 x 5 GHz: 3 dBi Built-in omnidirectional antenna
Physical interface
1 Gigabit Ethernet port 10/100/1000/2500 BASE-T, RJ-45 1 DC connector 1 reset button
LED indicators
1 power connector 1 LAN connector 1 2.4GHz connector 1 5 GHz connector
Power supply
Power supply via Ethernet: 802.3at input. Optional 12 V DC / 2 A power adapter.
Maximum power consumption
19.5 W
Operating frequency
Simultaneous use of two 2.4GHz and 5 GHz radio modules
Operating modes
Managed Mode: AP, Mesh Offline: AP, Mesh, WDS AP, WDS BR, WDS STA
Frequency radio
2.4GHz: 2400-2835MHz 5 GHz: 5150-5250 MHz, 5250-5350 MHz, 5470-5725 MHz, 5725-5850 MHz
Transmission power
Up to 23 dBm at 2.4GHz Up to 23 dBm at 5 GHz
Tx Beam Shaping (TxBF)
Radio circuits/spatial flow
4×4
SU-BY
Four (4) SU-MIMO spatial streams for 2.4GHz and four (4) SU-MIMO spatial streams for 5 GHz with wireless data transfer speeds up to 3548 Mbps per wireless client device with 2.4GHz and 5 GHz radio frequencies.
MU-BY
Four (4) Multiple (MU)-MIMO spatial streams with wireless data transfer speeds up to 2400 Mbit/s for simultaneous transmission to two (2) dual-stream wireless client devices with MU-MIMO 11AX support at a frequency below 5 GHz. Four (4) Multiple (MU)-MIMOS with wireless data transfer speeds up to 1148 Mbit/s for simultaneous transmission of two (2) two streams of wireless client devices with MU-MIMO 11AX support at a frequency below 2.4 GHz.
Supported data rates (Mbps):
802.11ax: 2.4GHz: 9 to 1148 (MCS0 to MCS11, NSS = 1 to 4) 5 GHz: 18 to 2400 (MCS0 to MSC11, NSS = 1 to 4) 802.11b: 1, 2, 5.5, 11 802.11a/g: 6, 9, 12, 18, 36, 48, 54 802.11 n: 6.5 to 600 Mbps (MCS0 to MCS15) 802.11ac: 6.5 to 1733 Mbps (MCS0 to MCS9, NSS = 1 to 4)
Supported radio technologies
802.11ax: Orthogonal Frequency Division Multiple Access (OFDMA) 802.11b: Orthogonal Frequency Division Multiple Access (DSSS) 802.11ac/a/g/n: Orthogonal Frequency Division Multiple Access (OFDM)
Sewage system
802.11ax supports Very High Bandwidth (VHT) — VHT 20/40/80MHz 802.11ac supports very high bandwidth (VHT) — VHT 20/40/80MHz 802.11n supports high Bandwidth (HT) — HT 20/40 MHz 802.11n supports very high bandwidth over 2.4GHz radio channel - VHT40 MHz (256-QAM) 802.11n/ac/ax packet aggregation: A-MPDU, A-SPDU
Supported modulation
802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM 802.11a/g/n: BPSK, QPSK , 16-QAM, 64-QAM 802.11b: BPSK, QPSK, CCK
