Max. capacity used
100 %
Main Input Voltage
230 B Alternating current 1 phase
Main Output Voltage
230 V AC 1 phase
Rated power [W]
900 W
Rated power
1600 VA
Input Connection Type
Schuko
output connection type
4 Schuko
Length
1,22 m
Number of cables
1
Battery Type
Lead-acid battery
Equipment included
User Manual
Pre-installed batteries
0
Free battery compartments
0
Typical recharge time
8 h
Battery voltage
24 V
Battery capacity
7,0 Ah
battery life
2…3 year(s)
Spare battery
APCRBC176
The possibility of increasing the autonomy time
0
The maximum value of the autonomy time
240 min
The number of unoccupied power modules
is 0
The number of slots occupied by power modules
is 0
reserve
No
UPS Size
WS
Colour
Black
Height
19 cm
Width
14 cm
Depth
39 cm
Net weight
10,2 kg
Mounting method
Paul
Type of fastener
No preference
Installation execution
Non - stable
two-support mount 0
USB-compatible
No
Network frequency
50/60 Hz +/- 5 Hz auto detection
Input voltage limits
140...300 V 230 B Alternating current
Cos phi
0,56
Maximum set power (W)
900 W
Output frequency
50/60 Hz +/- 1 Hz synchronized with the power grid
Type of UPS
Linear-interactive
Type of voltage form
Stepwise approximation of a sine wave
Autonomy time at full load
00:01:00 900 W
Graphic display
1
Autonomy time at half load
00:06:30 450 watts
Maximum set power (VA)
1600 VA
Switching time
The typical time is 6 ms, the maximum is 10 ms
Ambient temperature
0…40 °C
Relative humidity
0...95 % without condensation
Altitude above sea level
0...3000 m
Ambient temperature during storage
-15…40 °C
Relative humidity of storage
0...95 % without condensation
Storage height
0...3000 m
Acoustic level
40 dBA
Degree of protection IP
IP20
